Span 15m Workstation Bridge Crane With Rail Systerm Bus Bar

Product Description

Workstation Bridge Crane Single Beam Span 15m With Rail Systerm And Bus Bar

Single-girder overhead traveling crane is a lifting equipment which is used for lifting materials across the workshop, warehouse and yard.

Because it is located on both ends of a tall cement column or metal stent, shaped like a bridge.

The single-girder overhead traveling crane's bridge runs longitudinally along the tracks laid on both sides of the overhead crane, which can take full advantage of the space under the bridge to lift the materials without being hindered by the surface equipment.

It is the most widely used, the largest number of lifting machinery. Single-girder bridge crane is an important tool and equipment to realize the mechanization and automation of the production process in modern industrial production and lifting transportation.

Therefore, single-girder overhead traveling cranes have been widely used in indoor and outdoor industrial and mining enterprises, steel chemical industry, railway traffic, port terminals and logistics turnover departments and places.

Technical parameter of single girder overhead crane

Feature of single girder overhead crane

1.Single-girder crane, optimized design of imitation European crane, compact and simple atmosphere.

2.The single-girder crane has small volume, light weight, strong bearing capacity, small wheel pressure.

and low clearance, which effectively increases the space utilization rate, thereby reducing the investment cost of the plant by at least 15%.

3.Large lifting weight, uniform load and stable operation.

4.The main beam and end beam are connected by high-strength bolts and locating pins,which is easy to disassemble and reduce transportation costs.

5.Electric hoist or domestic first-line brand of international brands

Details of single girder overhead crane

Motor:Hoist Motor is a taper type rotor motor with braking, it is made by Nanjing special motor factory, it is of the best quality motors,it has bigger torque, so it can be adapted to moving frequently, the Maximum torque is 2.4-3 times than the rated torque.

Gear Box:Hoist Gear Box has specially treated gears for high wear resistance. Each Geared Shaft assembly is supported on ball or roller bearings, to ensure smooth, low-friction operation.

Wire Rope:Hoisting ropes comply with the exporting standards. The leading rope taken by the Drum does not slip sideways when slack. The factor of safety, on the nominal breaking strength of the rope is six.

Rope Drum:Grooved Drum, seamless pipe of adequate length to be wounded in one layer and to provide proper support for the rope to minimize abrasive wear is provided. Drum Shaft resolves on Ball Bearings for ensuring smooth running.

Electric apparatus controlling system:Model CD1 and MD1 is composed of the contactor box, controlling switch, cut-off limiter, the working voltage of controlling switch is 380V,36V or 24V(safety voltage).

Rope Guide:Rope Guide is in two halves, ensuring easy accessibility. It encircles the Drum completely so that the rope may not uncoil even when the Hoist is in unloaded condition. The rope guides of our company is thickened and dilated, so that it is not easy to be damaged.

Hook:The Hook Block is tested to 150 % of full load before assembly. The rope sheaves are fully guarded with protective steel casting. All sheaves rotate on ball bearing the pulley is thicken and dilated than domestic common pulley.
