Dia 6mm G80 5 Ton 1.5m Lever Ratchet Manual Chain Hoist

Minimum Order Quantity : 20 sets Packaging Details : High quality standard plywood box
Delivery Time : 7 days Payment Terms : T/T, L/C
Supply Ability : 100 sets
Place of Origin: China Brand Name: Silence
Certification: ISO CE Model Number: HSH

Detail Information

Chain: G80 Chain Diameter Of Load Chain: 6mm
Lift Speed: Upon The Pull Force Capacity: 0.75ton, 1.5ton, 3ton, 6ton, 9ton
Power Source: Hand Chain Color: Yellow Or As Required
High Light:

Ratchet Manual Chain Hoist

,

1.5m Lever Manual Chain Hoist

,

5T Manual Lever Chain Hoist

Product Description

Hot Selling Strong HSH Type 5 Ton 1.5m Lever Hoist Ratchet Manual Pull Lift





Product descriptions:


The hand lever hoist is a clamp body that ACTS on the load in rotation by manually pulling the handle with the help of the lever principle to obtain



the linear traction matching the load and drive the load to run.It has the advantages of compact structure, light weight, small size, easy to carry,



safe and reliable, long service life, small hand pulling force, small wear to wire rope and so on.It can be used for lifting, traction, descent,



calibration and other operations.If equipped with a special device, not only can non-linear traction work, and can be very convenient to choose the



appropriate operation position, or with a smaller tonnage of the machine doubled to expand its load capacity, for a larger tonnage of the load can



be used several machines and tools parallel work.







Dia 6mm G80 5 Ton 1.5m Lever Ratchet Manual Chain Hoist 0



Features:



1. Capacities: from 250kg to 9,000kg


2. Quality System Certification:ISO9001 GS, CE


3. Warranty:1 year



4. Lever block is a kind of highly efficient and versatile hand operated hoisting appliance.



5.It is particularly used in the narrow places, the open air and overhead places for pulling and stretching work at any angle.



6.The lever block is safe, reliable and durable.



7.The lever block is of excellent performance, easy operation and convenience maintenance.



8.The lever block is of small volume, light weight and portable in size.



9.The lever block is of high efficiency, fast lifting and light hand pull.



10.The structure is advanced and the appearance of lever hoist is attractive



Usage:


1, choose the appropriate size of the hand lever hoist for use, is strictly prohibited overload.


2. Carry out safety inspection on the hand-pulling hoist before use, and carry out no-load test on the hand-pulling hoist, and adjust the position of



the hook reasonably according to the actual requirements.


3, the adjustment method of the lower hook is: pull the dial block, make the dial block in the "N" position, rotate counterclockwise and pull the



release wheel, at this time, the clutch is in the open state, pull out the chain, you can easily adjust the hook position, after the adjustment should



be clockwise rotation handwheel, make it back to the original position.


4. After the adjustment, hang the weight in the middle of the hook and lift it by pulling the handle





Dia 6mm G80 5 Ton 1.5m Lever Ratchet Manual Chain Hoist 1Dia 6mm G80 5 Ton 1.5m Lever Ratchet Manual Chain Hoist 2Dia 6mm G80 5 Ton 1.5m Lever Ratchet Manual Chain Hoist 3







Product Parameter



HSH type lever hoist Specification
Capacity(t) 0.75T 1.5T 3T 6T 9T
Standard lifting height(m) 1.5m 1.5m 1.5m 1.5m 1.5m
Testing load(KG) 1125kg 2500kg 4500kg 7500kg 11250kg
Tensile force of full loading 250 310 410 420 420
Strands of load chain 1 1 2 3 4
Handle length(mm) 285mm 410mm 410mm 410mm 410mm
Gross weight(Kg) 6.7kg 11kg 17.5kg 25.5kg 49.8kg


Dia 6mm G80 5 Ton 1.5m Lever Ratchet Manual Chain Hoist 4

Workshop scene

Shipping and packaging



Dia 6mm G80 5 Ton 1.5m Lever Ratchet Manual Chain Hoist 5
