Double Speed 12 Ton Single Beam Bridge Crane A5 Working Class
Contact Person : Iris
Phone Number : +86 19939938244
WhatsApp : +8619939938244
|Minimum Order Quantity :||1 set||Price :||Negotiable|
|Packaging Details :||High quality standard exported plywood crate||Delivery Time :||15-20 days|
|Payment Terms :||Western Union, L/C, T/T||Supply Ability :||300 sets/per month|
|Place of Origin:||China||Brand Name:||Silence|
|Certification:||ISO CE||Model Number:||LD|
|Color:||Yellow Or As Your Request||Motor Brand:||Nanjing Special|
|Control Method:||Wireless Remote Control||Warranty:||1 Year|
|Max. Lifting Height:||35M||Lifting Speed:||5/0.83 M/min|
electric bridge crane,
electromagnetic overhead crane
Single girder overhead crane is a kind of new generation crane with intelligent feature. The lifting mechanism is European style ND steel wire rope electric hoist . The lifting speed is double. And Cross & long traveling use infinitely variable frequency motor which make the crane travel smoothly. The crane design is based on FEM,DIN, ISO standard, which is extremely safe, ergonomic, convenient, and efficient for material transport. Its compact size structure could save lots of space.
Technical parameter of single girder overhead traveling crane
|Loading capacity||0.5 ~ 32t|
|Lifting height||3 ~ 30 m or customized|
|Lifting speed||Vary with lifting capacity, or customized.|
|Lifting mechanism||Wire rope hoist or electric chain hoist|
|Working class||A3 ~ A5|
|Working temperature||-20 ~ 40 ℃|
|Control voltage||DC -36 / 48V|
|Motor protection class||IP54|
|Control way||Cabin, wireless remote, pendant push button.|
|Safety device||Buffer,current overload protection,overload device,power failure protection|
|Application area||Factory,workshop,warehouse,power station,logstic,etc.|
|Painting color||Yellow,Red or Customzied|
Advantage of single girder overehad traveling crane
1. The small wheel pressure and small volume can reduce the investment in the preliminary works such as the factory building.
2. Using high-quality components can reduce failure rate and maintenance costs.
3. Low consumption of total power can reduce the costs, it had remakeable energy-saving effect.
4. Variable Frequency control make cranes run smoothly.
5. Standardize the whole crane coninguration to make the whole machine more stable.
6. Real-time security monitoring while crane running.
7. The networking and automation of electric part, such as HIM human-computer interface, remote management of internet of things, electronic anti-shake function and automatic correction function and ect.
Configuration of single girder overehad traveling crane
1. Lifting motors(ABM)
2. Traveling motors ABB, Siemens, (Three-in-one type)
3. Electrics are Schneider,
4. SKF bearings
Safety feature of single girder overehad crane
1. Weight overload protection device
2. Top quality durable polyurethance buffer
3. Crane traveling limit switch
4. Low voltage protection function
5. Emergency stop system
6. Current overload protection function
7. Warning lights
8. Weight overload protection device
1. What's information should I provide to get the price?
More parameters, such as lifting capacity, lifting height, span, power supply, etc. And if you can give us your design drawing, that will be very helpful.
2. Which kind crane can you provide?
Weihua is a famous leading manufacturer with experienced designers, engineers and a 600- people R&D team to provide all kinds crane with customized parameters.
3. What services can you provide?
We have a complete pre-sales&after-sales service system, and our engineers are available overseas. And we also provide training for your crane operators.
4. Which brand are the accessories and electronic components in your cranes?
We have a long term cooperations with ABB, Siemens, Schneider, , etc. And we have world-leading processing machines which are imported from Japan and German.
5. Do you provide crane spare parts?
Yes, of course, we can provide motors, reducers, brakes, hooks, remote controllers, wheels, crane rails, end carriages, enclosed busbar and so on.
