Custom Size Port Crane Trolley Wheels , Bridge Crane Wheels On End Beam

Minimum Order Quantity : 1 sets Price : Negotiable
Packaging Details : packed by rain proof plastic cloth Delivery Time : 15 days
Payment Terms : L/C, T/T Supply Ability : 5 sets
Place of Origin: China Brand Name: Silence
Certification: ISO CE

Detail Information

Condition: New Temperature: Medium
OEM: Accept OEM Quality: 100% Inspected
Hardness: 300-380HB Wheel Diameter: 250-800mm
High Light:

overhead crane wheels

,

bridge crane wheels

Product Description

Custom Size Port Crane Trolley Wheel Bridge Crane Rail Wheel On End Beam





Product description



Forged & Casting Crane Wheels are available in a wide range of sizes. In addition, crane wheels to meet your special design requirements can be produced in virtually any size, configuration and surface finish condition.



Widely used in the Crane Manufacturer, The port authority, Transportation, Airlines, Railway locomotive, large-scale construction machinery and so on.



1) Material: 60#,65#,65Mn,50SiMn,42CrMoA (according to client's requirement)


2) wheel diameter: Φ300-2300mm


3) Tread Hardness:300-380HB OR Trand surface and rim quench hardness: HRC45-55 Trand surface and rim quench depth: 15-18mm


4) Measuring & testing equipment:Projecting profile, roughness tester, hardness tester, concentricity tester ect, UT ultrasonic detecting instrument


5)Size:Special designs are available,Making according to clients demand.Precise measurement and surface finishes are available.





Product process



Foundry technology


Casting is a casting liquid molding.



The advantages of casting are that it is used to manufacture parts with complex shapes that are difficult to forge and require high strength and plasticity, and the cost is low.



Forging Technology


Forging is a plastic deformation process, forging forming workpiece can improve the internal structure of the organization, good mechanical properties, grain uniformity, used for the important workpiece.




Product superiority



1. The material inspection and flaw detection after the completion of blank production are related to the stability of material performance, which is particularly important.



2. Machining, cutting, drilling, chamfering, deburring and polishing, strictly controlling the size and every detail.



3. Heat treatment can improve the comprehensive properties of toughness, hardness, wear resistance, fatigue strength and so on.



4. The bearing adopts the domestic and foreign first-line brand, ensuring the quality of the most core drive.



5. Wheel detection: size, material, hardness, flaw detection, etc.



6. Appearance and packaging: finish cleaning, painting, anti-rust oil, plastic film covering, wooden case packing.



Custom Size Port Crane Trolley Wheels , Bridge Crane Wheels On End Beam 0





Technical parameters

Custom Size Port Crane Trolley Wheels , Bridge Crane Wheels On End Beam 1





No. Item Drg.No DIMENSIONS(mm)                             Weight
      D(h9) D1 A A1 h h1 b b1 d I d4 L L1 G b2
1 Drive wheelsΦ500 1764 500 540 280 213.5 310 140 230 50 75 105 M24 400 230 79.5 20 284
2 Drive wheelsΦ500 1765 500 540 280 213.5 310 140 230 50     M24   230     277
3 Drive wheelsΦ600 1766 600 640 280 213 310 140 230 50 85 130 M24 415 230 90 22 332
4 Drive wheelsΦ600 1767 600 640 280 213 310 140 230 50     M24 415 230     322
5 Drive wheelsΦ700 1768 700 750 315 240 350 160 235 80 90 130 M30 455 260 96 25 508
6 Drive wheelsΦ700 1769 700 750 315 240 350 160 235 80     M30   260     495
7 Drive wheelsΦ800 1770 800 850 365 280 410 190 275 90 95 130 M30 500 300 100 25 756
8 Drive wheelsΦ800 1771 800 850 365 280 410 190 275 90     M30   300     743



Technology



Custom Size Port Crane Trolley Wheels , Bridge Crane Wheels On End Beam 2
