Product Description
5 Ton Material Transfer Cart Material Handling Equipment Used In Warehouses
Configuration instruction
BXC series battery power flat car, is the rail flat car provided by the battery power, storage battery installed in the flat car, the power supply through the electrical control system, to provide power to the dc traction motor. To start, stop, forward, backward, speed adjustment, etc.
Functional description
Battery electric flat car, also called electric across a car, rail inside the plant is a kind of electric transportation vehicles, has simple structure, convenient use, load can be strong, not afraid dirty not afraid to hit, easy maintenance, long service life, etc, because of its convenient, economical, practical, easy to clean, and many other advantages, as for the enterprise internal and factory and workshop between regular, fixed schedule when moving heavy objects of transport.
1. Load-bearing transportation is the most basic and important function of electric flat cars. This series of flat cars can run on s-shaped, c-shaped and other arc-shaped tracks.
2. The hydraulic lifting system can be installed on the electric flat car to achieve lifting and other functions.
3. The flat car can realize the power and energy of the side dump by the hydraulic device.
4. Safety devices can be installed on the electric flat car, such as proximity switch, stop in case of contact, alarm system, buffer, etc. to achieve the corresponding safety functions.
5. According to the reasonable requirements of customers, the company can develop the corresponding non-standard electric flat vehicle to achieve the required functions
Security configuration
1. Stop and sound and light alarm device can effectively protect the personal safety of staff.
2. Limit position and anti-collision buffer device can effectively prevent the end of the electric flat car from derailing and effectively avoid the damage to the car body.
In an emergency, the emergency stop button can help stop the flat car.
Product superiority
1. This series of flat cars has the advantages of safety, mobility and flexibility, the operation is not limited by distance, the speed is adjustable, the dc motor of flat cars has the advantages of stable start, large start torque, small impact on the reducer, low voltage, long service life and so on.
The track laying requirements are not high, suitable for use frequency is not high, long-distance transport occasions.
2. The transfer cart adopts dc motor, suitable for frequent use, with higher safety and mobility flexibility.
It can be equipped with hard tooth surface reducer to make the maintenance of flat car easier.
3. This series of electric flat car mechanism is relatively simple, convenient for maintenance, easy to disassemble and assemble, strong bearing capacity, long service life, low requirement for track laying, low cost, suitable for harsh environment, high-temperature environment, and other occasions.
4. Transfer cart is suitable for all kinds of environment, can work in indoor, outdoor, flammable and explosive environment, can also be added to the flat car hydraulic device, buffer device. Simple operation, in the case of transport distance is far, can be added on the flat car with the operating platform, to meet the customer long-distance transport, to achieve a humanized design.
5. PLC control system can be added to the flat car, automatic rail car, greatly increase the work efficiency.
Technical parameters
| Model | BXC-2T | BXC-20T | BXC-50T | BXC-63T | BXC-100T | BXC-150T |
| Capacity(T) | 2 | 20 | 50 | 63 | 100 | 150 |
| Wheel base(mm) | 1200 | 2800 | 4200 | 4300 | 4900 | 7000 |
| wheel back distance(mm) | 1200 | 1435 | 1435 | 1435 | 2000 | 2000 |
| Wheel diameter(mm) | 270 | 350 | 500 | 600 | 600 | 600 |
| Number of wheel(pcs) | 4 | 4 | 4 | 4 | 4 | 8 |
| Ground clearance(mm) | 50 | 50 | 50 | 75 | 75 | 75 |
| Speed(m/min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 |
| Power(Kw) | 1 | 2.2 | 5 | 8 | 10 | 15 |
| Accumulator capacity(A/H) | 180 | 180 | 330 | 400 | 440 | 600 |
| Battery voltage(V) | 24 | 48 | 48 | 72 | 72 | 72 |
Product application
