Lifting Cargo Pneumatic Chain Hoist 1-50 Ton For Mining Easy Maintenance

Minimum Order Quantity : 1 set Price : Negotiable
Packaging Details : High quality standard plywood box Delivery Time : 10 work days
Payment Terms : T/T, L/C, Western Union Supply Ability : 300 sets/per month
Place of Origin: China Brand Name: Silence
Certification: ISO CE Model Number: HQ

Detail Information

Capacity: 8-20Ton Lowering Speed: 3m/min
After-sales Service Provided: Online Support Weight: 500kg
Material: Chinese G80 Applicable Industries: Manufacturing Plant
High Light:

electric chain block hoist


pneumatic chain hoist

Product Description

1ton-50ton Pneumatic Chain Hoist Lifting Cargo Air Hoist Used For Mining

Product description


The electric hoist is widely used in lifting heavy weight or installed in a single beam cranes, linear, curve strander beams. It can also be used to the hoist double beam, gourd gantry crane or cantilever crane.

It is a light equipment for lifting, which is welcomed by Industrial and mining enterprises, railways, docks, warehouses.


In general of air chain hoist

1. Compact, light weight, safe and reliable
2. Components and parts apply used universally,strong compatibility
3. High lifting capacity, easy maintenance
4. Easy operation, accurate lifting steady operation


Air chain hoist motor

1. To use higher starting torque tapered rotor braking asynchronous motor

2. No need plus brake again,

3. Motor load keeping rate is 25%,Safe and reliable

4. Class B or Class F insulation,Motor protection grade IP44 / IP54


Air chain hoist reducer

1. it adopts 3-GRADE fixed axle inclined gears structure,long life
2. The gears and gear shaft made by the alloy steel of heating treatment,high strength
3. Box, box cover made by high quality cast iron,Assembly rigor, good seal
4. The gear reducer become to be a single part,loading and unloading is extremely convenient
5. Reliable drive, high mechanical efficiency.


Air chain hoist protection function

It has the device up and down proceeding to protect the fire cutting limiting stopper.

To ensure the safe operation of the electric hoist, the electrical components have long life, use reliable

It also has device to prevent clashing the top.


Technical parameters


Model HQ8 HQ10 HQ12 HQ18 HQ20
Work level M3 M3 M3 M3 M3
Mine safety certificate No. MAJ150309 MAJ150305 MAJ150310 MAJ150307 MAJ150308
Capacity 8T 10T 12T 18T 20T
Air pressure 6Bar 6Bar 6Bar 6Bar 6Bar
Lifting height 3m 3m 3m 3m 3m
falls of chain 3 4 4 3 4
Lifting motor power 3.5KW 3.5KW 3.5KW 3.5KW 3.5KW
Full load 1.2m/min 1m/min 1m/min 0.9m/min 0.7m/min
Lifting speed
Full load 3m/min 2m/min 2m/min 1.9m/min 1.6m/min
lowering speed
Lifting motor 5.5cbm/min 5.5cbm/min 5.5cbm/min 5.5cbm/min 5.5cbm/min
air consumption
Lifting motor Rc1/2 Rc3/4 Rc3/4 Rc3/4 Rc3/4
Air connection
Supply hose inside 25mm 25mm 25mm 25mm 25mm
Lifting chain size 13*36mm 13*36mm 13*36mm 13*45mm 13*45mm
Length of control hose 3m 3m 3m 3m 3m
Sound level 79dB 79dB 79dB 78dB 78dB
Traverse motor power 2*0.25KW 2*0.25KW 2*0.25KW 0.7KW 0.7KW
Traverse speed 10m/min 10m/min 10m/min 5m/min 5m/min
Traverse motor 2*0.6cbm/min 2*0.6cbm/min 2*0.6cbm/min 1.3cbm/min 1.3cbm/min
air consumption
traverse motor Rc1/4 Rc1/4 Rc1/4 Rc1/4 Rc1/4
air connection
traverse motor G3/4 G3/4 G3/4 G3/4 G3/4
supply hose inside dia
Traverse motor 200kg 200kg 200kg 260kg 260kg
Total weight 358kg 358kg 388kg 688kg 688kg



Lifting Cargo Pneumatic Chain Hoist 1-50 Ton For Mining Easy Maintenance 0

Model HQ8 HQ10 HQ12 HQ18 HQ20
b /beam width 200-250mm 200-250mm 200-250mm 250-300mm 250-300mm
Min radius 6500mm 6500mm 6500mm 6500mm 6500mm
A 115mm 115mm 115mm 168mm 168mm
B max 326mm 362mm 326mm 372mm 372mm
C 168mm 168mm 168mm 320mm 320mm
D diameter 165mm 165mm 165mm 185mm 185mm
E 1030mm 1030mm 1030mm 650mm 650mm
F 530mm 530mm 530mm 274mm 274mm
G 198mm 198mm 198mm 220mm 220mm
Hmin 966mm 966mm 966mm 1125mm 1125mm
J 236mm 236mm 236mm 370mm 370mm
K 335mm 335mm 335mm 394mm 394mm
L 680mm 790mm 790mm 318mm 318mm
N 546mm 592mm 592mm 174mm 159mm
M 50mm 50mm 50mm 46mm 46mm
Ф 63mm 63mm 63mm 71mm 71mm


Lifting Cargo Pneumatic Chain Hoist 1-50 Ton For Mining Easy Maintenance 1


Lifting Cargo Pneumatic Chain Hoist 1-50 Ton For Mining Easy Maintenance 3
