7T Portable Gantry Crane

Product Details:
Place of Origin: China
Brand Name: SILENCE
Certification: ISO CE
Model Number: PT
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1000-5000/set
Packaging Details: Electrical, hoist and other parts packed by high quality plywood crate; Beams packed by rain proof plastic cloth
Delivery Time: 10 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 10 sets

Detail Information

Warranty: 12 Months Hoist: Wire Rope Hoist Or Chain Hoist
Material: Steel Or Aluminum Height: Fixed Or Adjustable
Color: Customer Requirements Application: Outdoor And Indoor
High Light:

7T Portable Gantry Crane


span 2m Portable Gantry Crane


7T adjustable gantry crane

Product Description

5 Ton Simple Portable Gantry Crane Efficient Handling To Reduce Labor Costs
Product description of Portable Gantry Crane


This product is a new type of gantry frame developed by us according to the needs of truck repair shop lifting maintenance heavy equipment and material transportation.


The advantages of the mobile gantry are that it can be moved at will, convenient for disassembly and installation, covers a small area, and can be transferred to another site for installation and use by a mini car.


The width and height can be adjusted in different levels. The steel structure is designed rationally and can bear the weight from 10,000kg.In addition, our company can also be customized according to the actual needs of users.



Technical parameters of Portable Gantry Crane


Item Mini mobile gantry crane
Capacity 0.5ton 1ton 2ton 3ton 5ton
Span 2~12m(as your require)
Lifting height 1~6m(as your require)
Lifting equipment Manual/Electric wire rope or chain hoist
Working voltage 3P 380V 50Hz
Working class A4
Attention: Above parameters suitable for our company’s standard products, meanwhile,please make contact with our sales manager if you were interested in customized products.

Operating rules of Portable Gantry Crane



1. Load test lifting shall be carried out after the gantry frame operation (assembly) is completed;The test crane is divided into static load and dynamic load to check the operating capacity, bearing capacity, stability and reliability of each system.

2. When the gantry is running, it should be parallel and stable without distorting it.

3. Overload use is strictly prohibited.

4. The operation shall be under the unified command of specially-assigned personnel, and the other personnel shall have a clear division of labor;Determine a uniform contact signal.

5. In case of power failure or other special circumstances during the operation, the heavy objects should be dropped to the ground instead of being suspended in the air.

6. It is strictly prohibited to stand under the gantry and the heavy objects lifted.

7. It is forbidden to stand on the gantry when it is running.


 7T Portable Gantry Crane 0
7T Portable Gantry Crane 1



Features of Portable Gantry Crane


1. With a jack-up device, erection and disassembly can be completed independently by the working mechanism set up by itself.The height increases with the rise of the building.Set up labor - saving, low cost.

2. The construction condition is refreshed by using the attachment rod without wind rope.

3. When erecting and disassembling, there are always two standing and living together, and the work is rated as stable and reliable.

4. Manual hoist jack-up platform is adopted, standard section is installed with lever, low labor intensity.

5. The rope breaking protection device is adopted. Once the rope is broken for some reason, the boards on both sides of the basket will stick the basket in the air and prevent the basket from falling to the ground.



7T Portable Gantry Crane 2


Packing and shipping of Portable Gantry Crane


7T Portable Gantry Crane 3

7T Portable Gantry Crane 4
