Construction Electric Wire Rope Hoist 1000kg High Efficiency Stable Performance

Minimum Order Quantity : 1 set Price : Negotiable
Packaging Details : High quality standard exported plywood crate Delivery Time : 7 days
Payment Terms : T/T, L/C, Western Union Supply Ability : 300 sets/per month
Place of Origin: China Brand Name: Silence
Certification: ISO CE Model Number: CD

Detail Information

Usage: Construction Hoist Lift Speed: 5m/min, 10m/min
OEM: Accept Power: Single Phase
Working System: M3-M4 Sling Type: Wire Rope
Ambient Temperature: -25~40
High Light:

electric trolley hoist

,

electric cable hoist

Product Description

High Efficiency Construction Hoist 1000kg Electric Wire Rope Hoist



General introduction



PA electric hoist motor with automatic brake system and thermal protection function.It has Emergency stop switch and Positive and negative switch which can ensure safe and smooth operation.
It has emergency stop switch and forced open limit switch. The protection class is IP54, and has thermal protection device. PA electric Hoist Can Be Easily Lift Small Engines, Transmissions, Large Shop Tools, Or Building Supplies.
PA electric hoist has CE/GS certification, the quality is safe and reliable. All the products of the hand brand are insured by PICC without worries.



Product parameter



type PA200 ​PA300 ​PA400 ​PA500 ​PA600 ​PA800 ​PA1000
capacity (KG) 100/200 150/300 200/400 250/500 300/600 400/800 500/1000
lifting height(m) 12/6 12/6 12/6 12/6 12/6 12/6 12/6
lifting speed(m/min) 10/5 10/5 10/5 10/5 10/5 10/5 10/5
traveling speed(m/min) 16 16 16 16 16 16 16
power(kw) 0.48 0.6 0.95 1.02 1.2 1.3 1.6
voltage 1p 220v-240v 50/60 hz
weight(kg) 11 11 18 18 19 20 31





























​This parameter is for reference only, specific requirements can contact us for customization.



Product feature

1. Copper wire can be limited to reduce the accident rate .caused by bad weather or overload use with good anti-oxidation,corrosion-resistant and stable performance.
2. Gear and gear shaft are used by 40Cr or Cr MnTi steel ,forging processing with heat treatment .
3. Electric Hoist Lift Durable Braided Anti Twist High Carbon Steel Line Cable.

4. When Limit Baffle Hit Limiting Stopper, The Hoist Will StopTautomatically.
5. IF Wire Rope Reverse to Acsend, The Hoist Motor Will Stop Automatically.
6. 220V Power Supply
7. The Hoist Hook Can Rotate 360°.



Construction Electric Wire Rope Hoist 1000kg High Efficiency Stable Performance 0

Construction Electric Wire Rope Hoist 1000kg High Efficiency Stable Performance 1

Construction Electric Wire Rope Hoist 1000kg High Efficiency Stable Performance 2
